Name: Z8
Brand: Colorlight
SKU: 1-3-1-CP-Z85UDZ006
Availability: BackOrder

$10,000.00

The Z8 LED display controller delivers 13.01 million pixel capacity, versatile 4K input options, HDR10/HLG support, and advanced processing for high-end LED displays. Price includes chassis only. Input and Output cards are sold separately

10 features of the Colorlight Z8

Supports multiple 4K input formats: HDMI 2.0, DP 1.2, 12G-SDI, and ST2110
Input frame rate range from 23.98Hz to 240Hz with 8/10/12-bit video depth
Output capacity up to 13.01 million pixels with 16,384-pixel width or 8192-pixel height
Multiple output board options including 5G and 10G fiber, with loop redundancy
Advanced video processing with cropping, scaling, splicing, and 4-layer display
HDR10 and HLG wide-gamut support for superior brightness and contrast
Genlock input and loop for seamless synchronization across devices
Precision color management with 3D-LUT and RGB-based adjustments
Redundant design with backup ports for stable performance in mission-critical applications
Flexible control via USB, RS232, LAN, and cascading options

Available on backorder

SKU: 1-3-1-CP-Z85UDZ006 Categories: LED Processors, Splicers, Z Series Tags: processors, Z-Series Brand: Colorlight

Description
Additional information

Description

The Z8 is a high-performance LED display controller designed for large-scale, high-end applications requiring superior video quality and reliable performance. With support for multiple input options including HDMI 2.0, DP 1.2, 12G-SDI, and ST2110, it delivers flexible 4K input configurations up to 4096×2160 at 60Hz and supports frame rates from 23.98Hz to 240Hz. Offering 8-bit, 10-bit, and 12-bit video depth with full HDCP compliance, the Z8 ensures outstanding image fidelity and security.

On the output side, the Z8 provides up to 13.01 million pixels of load capacity with a maximum width of 16,384 pixels or height of 8192 pixels, and supports multiple output board configurations including 5G and 10G optical fiber options. It also features loop redundancy for maximum system reliability. Advanced video processing functions include cropping, scaling, broadcast-level splicing, 4-layer display, HDR10/HLG, and ultra-low latency. The Z8 also offers robust color management with 3D-LUT support, precise brightness and temperature adjustments, and Genlock synchronization for smooth playback.

With RS232, USB, and LAN controls, along with swappable input and output boards, the Z8 provides unmatched flexibility for demanding LED display projects such as live events, XR production, broadcasting, and large-scale installations.
